P15.6 – 15.6 Transparent Mesh LED Display
Transforming Architectural Spaces with Transparent LED Displays
Our P15.6 – 15.6 Transparent Mesh LED Display is engineered for commercial facades, retail branding environments, architectural media displays, and modern digital installations requiring lightweight transparent display technology with balanced visibility and performance.
Designed with high-transparency mesh structures and lightweight aluminum frames, this display delivers vibrant visuals while preserving natural lighting, airflow, and architectural aesthetics. Its modular structure and energy-efficient design make it ideal for commercial building integrations and creative digital signage applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Pixel Pitch (mm) | 15.6 – 15.6 mm |
| LED Type | DIP 3 in 1 |
| Cabinet Dimension (W x H x D) mm | 1000 x 1000 x 105 |
| Weight (kg/m2) | 23 |
| Service Access | Front / Back |
| Maximum Brightness (nits) | 8000 |
| Viewing Angle | 110 x 110 |
| Max Power (W/m2) | 450 |
| Refresh Rate (Hz) | ≥ 3840 |
| Ingress Protection (IP) Rating | Front IP65 / Back IP54 |
| Cabinet Type | Die Cast Al |
| Data Processing | 13–15 Bit |
Need the full datasheet or a quote for P15.6 – 15.6 Transparent Mesh LED?
Connect with our LED engineers for detailed mechanical drawings, power distribution schematics, and custom pricing.
Engineered for High-Performance Architectural Applications
The P15.6 – 15.6 Transparent Mesh LED Display is optimized for architectural and commercial environments requiring high transparency, lightweight installation, and stable visual performance.
- High transparency preserves architectural visibility and natural lighting
- Lightweight mesh structure enables flexible installation applications
- High brightness ensures strong indoor and outdoor visibility
- Modular cabinet system supports scalable display installations
- Energy-efficient design ensures reliable long-term operation
Applications
- Commercial facades (example: digital building branding displays)
- Retail storefronts (example: transparent promotional displays)
- Shopping malls (example: architectural media installations)
- Glass curtain walls (example: transparent LED branding screens)
- Public spaces (example: creative digital communication displays)
Key Benefits
- Designed for commercial architectural display installations
- Transparent mesh structure maintains open building aesthetics
- High brightness ensures strong visual display performance
- Lightweight modular system supports scalable installations
- Energy-efficient operation for continuous display applications
Engineered for Global LED Excellence
- Global manufacturing expertise across China and India ensuring quality
- Advanced LED components deliver high brightness and color accuracy
- High refresh rate ensures smooth and flicker-free visuals
- Precision PCB and IC engineering ensure stable display performance
- Durable cabinet structures designed for long-term reliable performance
- Energy-efficient systems reduce power consumption and operational costs
- Modular LED design enables flexible installation and scalability
- Consistent visual output ensures uniform brightness and seamless viewing
